FinishForce PRO - BR1600 - Industrial Deburring & Edge Rounding
$70,650.00
*ex GSTEngineered for maximum output and consistency, the Koenig FinishForce BR1600 is the flagship model of the BR-Series. Designed for large-scale metal fabrication and high-volume production, it integrates advanced LinishPro belt configurations with the Pro Finish Flap Wheel 360, enabling fast stock removal, fine surface finishing, and uniform edge rounding across wide workpieces. The 1600mm working width easily handles full-size panels, frames, and structural components. With optional MagnaForce, VacuForce, or FlexiForce tables, it ensures total stability and precision handling for both ferrous and non-ferrous metals. The BR1600 delivers unmatched productivity, finish uniformity, and reliability — setting a new benchmark for industrial metal finishing systems.
For non-ferrous materials such as aluminium, Koenig offers the FinishForce BW-Series (WetLine), purpose-built for wet wide-belt sanding.
For applications where wet sanding and edge rounding aren’t required, and precision finishing of ferrous metals is the priority, the FinishForce B-Series provides a versatile range of sizes and configurations.
For applications where wet sanding and edge rounding aren’t required, and precision finishing of ferrous metals is the priority, the FinishForce B-Series provides a versatile range of sizes and configurations.
⚡ Get 10% Off Laser Materials… Forever!⚡
Automatically applied to your account with every Koenig Machine purchase. Explore our material range
Australian Based Local Support for Life
Setup & Training by Expert Local Technicians
10% Off Laser Materials for life on all Machines
10+ Years as the Aussie Laser Specialists
Specifications
| Technical Parameters | BR800 | BR1000 | BR1300 | BR1600 |
|---|---|---|---|---|
| Working Width | 800mm | 1000mm | 1300mm | 1600mm |
| Minimum Working Length | 300mm (or use a template/jig for smaller parts) | |||
| Maximum Conveyor Speed | 25m/min | |||
|
Machine Dimensions (L × W × H mm) Note: Dimensions shown are based on the maximum configuration (2 sanding belts 1 flap wheel & 1 scotch brite roller) and may vary depending on selected machine configuration. |
4500 × 1800 × 2250mm | 4500 × 1950 × 2250mm | 4800 × 2150 × 2500mm | 4800 × 2200 × 2500mm |
| Table Type Options | 100% Magnetic Hold-Down • 100% Vacuum Hold-Down • Hybrid (30% Magnetic / 70% Vacuum) | |||
| Abrasive Belt Grit Options | 80, 120, 180, 240, 320 | |||
| Pro Finish Flap Wheel Size | 300×300×40mm | 300×250×40mm | 300×300×40mm | 300×400×40mm |
| Flap Wheel Brush Quantity | 4 | 6 | 8 | 8 |
| SANDING CONFIGURATION SPECIFICATIONS | ||||
| LINISHPRO SOLO + PRO FINISH FLAP WHEEL 360 | ||||
| Weight (kg) | 2600 | 2800 | 4200 | 4600 |
| Power Supply | 415V 50Hz 3 Phase – 60A | 415V 50Hz 3 Phase – 65A | 415V 50Hz 3 Phase – 80A | 415V 50Hz 3 Phase – 90A |
| LINISHPRO DUOS + PRO FINISH FLAP WHEEL 360 | ||||
| Weight (kg) | 3100 | 3300 | 4600 | 5300 |
| Power Supply | 415V 50Hz 3 Phase – 80A | 415V 50Hz 3 Phase – 85A | 415V 50Hz 3 Phase – 100A | 415V 50Hz 3 Phase – 110A |
| LINISHPRO SOLO + PRO FINISH FLAP WHEEL 360 + SCOTCH-BRITE PRECISION POLISH ROLLER | ||||
| Weight (kg) | 3100 | 3300 | 4700 | 5200 |
| Power Supply | 415V 50Hz 3 Phase – 65A | 415V 50Hz 3 Phase – 70A | 415V 50Hz 3 Phase – 100A | 415V 50Hz 3 Phase – 110A |
| LINISHPRO DUOS + PRO FINISH FLAP WHEEL 360 + SCOTCH-BRITE PRECISION POLISH ROLLER | ||||
| Weight (kg) | 3600 | 3800 | 5300 | 5900 |
| Power Supply | 415V 50Hz 3 Phase – 100A | 415V 50Hz 3 Phase – 110A | 415V 50Hz 3 Phase – 120A | 415V 50Hz 3 Phase – 160A |
| Specifications subject to change without notice. | ||||
