RayTools Cutting Head Seal Ring 11021M2110005

The RayTools Seal Ring, part number 11021M2110005, is a precision-engineered component designed to ensure optimal performance and protection for your fiber laser cutting head. Measuring 42.5mm x 40mm x 3.2mm, this seal ring is specifically crafted for use with RayTools models BM114, BM114S, BM114TC, BM114E, BM115 AND BS08K

Key Features:

• High-Quality Materials: Constructed from high-purity, transparent PTFE, the seal ring offers exceptional wear resistance. The integrated stainless steel spring is made of ultra-thin, high-hardness material, providing excellent flexibility and high yield strength.

• Enhanced Protection: Installed in the protective lens drawer, this seal ring forms an interference fit with the lower protective lens. This design effectively seals the area beneath the focusing lens, preventing dust and contaminants from entering the cutting head cavity. Such protection is crucial in safeguarding the focusing lens and collimation mirror group from potential damage.

• Precise Dimensions: With exact measurements of 42.5mm x 40mm x 3.2mm, the seal ring ensures a perfect fit and reliable sealing performance for the specified RayTools cutting head models.

Incorporating the RayTools Top Seal Ring 11021M2110005 into your laser cutting system enhances the longevity and efficiency of your equipment, ensuring consistent and high-quality cutting performance.
