LF60M 3kW Fiber Laser Tube Cutter – Showroom Special

$139,500.00 $119,500.00 SAVE $20,000.00
SKU: LF60M-SR

LF60M 3kW Fiber Laser Tube Cutter – Showroom Special
**Finance from $2,985/month over 48 months**

Secure serious tube laser capability at a heavily reduced showroom price. This 3kW Fiber Laser Tube Cutting Machine is available immediately — no lead times, no waiting.

Key Features

  • 3kW Fiber Laser Source
  • Cuts tube up to 7m long
  • 20–280mm diameter capacity
  • Cuts up to 20mm mild steel / 10mm aluminium
  • Pneumatic auto-clamping (no chuck changeovers)
  • Automatic tube supports for long material
  • 2m pneumatic outfeed table with 3m bin tray
  • Fully enclosed cutting head for safety


Built for Real Fabrication

Cut round, square, rectangular tube, I-beam, H-beam, C-channel and custom profiles. Optional 5-axis cutting allows 45° and bevel preparation — reducing secondary processing and welding time.

Perfect for structural steel, handrails, frames and general fabrication work.

Immediate delivery available.
Enquire today to book a showroom demo.

*Finance subject to approval.

In Stock

Subtotal: $108,636.36

Add to Wishlist

American Express Apple Pay Google Pay Mastercard PayPal Shop Pay Visa
Technical Parameters Specification
Laser Power 3kW
Tube Length LF60M – 6m standard model
Minimum Waste Stock Length 100mm
Clamp Diameter 20–280mm chuck
Tube Weight Capacity 280mm chuck = 400kg
Laser Source Type MAX
Cooling Type Industrial water cooling – S&A water chiller
Moving Speed 30m/min
Acceleration 1.5G
Positioning Accuracy ±0.03mm
Re-positioning Accuracy ±0.02mm
Minimum Line Width 0.1mm
Controlling Software Cypcut Control System 5000
TubesT Lite (standard) or TubesT Pro upgrade
Graphic Formats Supported AI, DXF, PLT, Gerber, G-code
Compatible Software Illustrator, Photoshop, CorelDraw, AutoCAD, SolidWorks, MasterCam, Type3, Wentai
Power Supply 3kW – 415V 50Hz 50amp
Working Environment Temperature: 0–45°C
Humidity: 5–95% (no condensate)
